Performance WPC Production Line / Wood Plastic Composite Machinery For Furniture and Door
Quick detail:
1. the main components of WPC board extrusion line including:
1. powder feeder
2. twin-screw extruder
3. mould
4. vacuum calibration and cooling unit
5. haul-off unit
6. cutting unit
7. profile stacker
Auxiliary machines of PVC pipe machine:
1. mixing unit
2. printer
3. crusher and milling machine
4. water chiller and air compressor..etc
Description:
1. our wpc wood plastic board extrusion machine, compounding domestic and abroad technology, with characters of high automatic level, steady performance, large output and high efficiency. it has such characteristics as high impact resistance , high rot resistance , high temperature resistance , non-toxic , smooth surface , light , easy to thermoform , etc.
2. pvc powder+wood powder+additives → mixing → extrusion line ( conical twin-screw extruder → profile extrusion die → profile moulds→ vacuum calibration platform →haul-off → cutter →stacker → finished product) → surface finish processing ( like heat transfer,sanding, embossing,etc).
3. The wpc board has many applications , such as wire plate , environment protection material , venting equipment , etc. production socope : thickness 1-30mm , width 3000mm(etc).
Specifications:
| Model | SJSZ80/156,SJSZ92/188 |
| usage | extrusion outdoor decorative |
| raw material | recycled PVC,wood powder, additive material,etc |
| product size | 1220*2440 |
| Extruder feature | Special designed extruder |
| wood powder ( wood fiber) | high volume of addition up to 50~75 percent |
| Plastic proceed | PP,PE,PVC,wood plastic composite |
| Auxiliary machine | Emboss machine,sanding machine,polishing machine |
| Product type | WPC foamed board extrusion line,WPC crust furniture foamed board machine |
Competitive Advantage:
1.good after-service , engineers can availiable go abroad to serive.
2.spare parts are free
3.guarantee:one year or according to customer’s requirement.
4.advanced technology and best quality
5.international certification standard.
6.our engineer help and teach customer to test the machine.
